Ortlieb introduces Thru Axle based rack mounting system

Ortlieb has launched its latest offering, which comes in the form of a Thru Axle-based system with Quick-Rack compatibility for modern bikes, especially those without fender eyelets.

The Thru Axle M6-Connector is a universal adapter Thru Axle designed for the secure mounting of racks. Made from aluminium, with integrated M6 threads, this is said to offer “exceptional versatility and durability”.

1. This adapter replaces axles up to 180 mm in length and can be adjusted to fit axle lengths between 165 mm (tapered) and 168 mm to 180 mm using the included spacers.
2. It is also compatible with shorter axle lengths, provided the axle can be screwed through the frame.
3. Available in three thread pitches and fully compatible with SRAM UDH/Transmission, this thru axle is the ideal solution for demanding applications, ensuring a secure and reliable fit.

Quick-Rack

The new Quick-Rack is designed to be adaptable and versatile – offering three mounting options

1. Direct mounting for bikes with M5 or M6 threaded eyelets – “with supplied snap-in knobs.”
2. Thru Axle M6 connector and attach the Quick-Rack directly to the axle.
3. Use the optional Seat Stay Adapter to mount the Quick-Rack on the bike

Mounting the Quick-Rack is possible on road, gravel or mountain bikes and commuter bikes – in only 15 seconds – enabling riders to transform almost any bike into an all-rounder for everyday use.

• Struts with a diameter of 10 mm support a payload of up to 20 kilograms.
• Quick-Rack is suitable for use with all of the brands existing fixation systems, ensuring users can combine it with any Ortlieb bag.

Thanks to the two hanging levels and a platform, riders can also use and fasten panniers and a basket at the same time. The optional mudguards make sure that the system is primed for year-round use.

Offered in four sizes – Quick-Rack Light, Quick-Rack, Quick-Rack L, and Quick-Rack XL – Ortlieb also points out that the system is “Licensed by Tailfin for the use of a Thru Axle M6-Connector with a Quick-Rack L or XL in the US and the UK (Patent No.GB 2 542 644 and US 10,654,540)“

In the UK, Ortlieb is distributed by Lyon Cycle.
